Solar Pump station - FlowCon MAX FA - Hi Flow 1
Commercial Solar Pump Station PAW FlowCon FA MAX PAW FlowCon FA MAX - Integrated pump station with Wilo Star S30 3-speed solar pump. For Large Commercial Systems requiring higher flow rates
Model: N-69 Shipping
Weight: 10lbs
Manufactured by: PAW
Download Product Specification PDF Complete solar control system including solar working station with drain fill valves and shut off isolation valves. Patented air scope, flow meter, pressure release valve, pressure gauge, temperature gauge. Wilo Star S31 3-speed high volume pump included. Quality brass components are high temperature rated.
Note: Requires RESOL controller - comes with 1" compression connections.
USE in closed loop design only. The circulation unit is used on the primary circuit of solar heating systems to control the temperature in the hot water storage. The pump inside the unit is activated by the signal from the differential temperature regulator. In addition, this unit contains the functional and safety devices for optimum circuit control. FEATURES
All medium-bearing parts are made of brass
All connections 3/4 " female
With Pre-assembled steel wall bracket, with the PAW-mounting set to be installed directly to the tank
Full port ball valve in return pipe is noise-free, low pressure drop, manual opener for faster line drain service, spring-actuated - special design for solar thermal applications
Large ball valve handles for easy grip, and visible closing position
Air-Scoop in the supply line for a permanent degassing of the heat transfer medium
Function-optimized design insulationmade of durable elastic EPP; 100% insulation of the fittings - excellent pump ventilation and cooling
Solar safety assembly Pressure relief valve 86 PSI high-temperature manometer 0 - 90 PSI with Drain valve for flushing and filling, flat sealing connection for expansion tank
Full metal solar thermometer, 32-320°F (0 - 160°C) can be pulled-off, with immersion sleeve being integrated in the ball valve
Fully assembled with flat sealing union connections at most joints
Pump can be isolated for servicing
Flow meter Flow quantity measuring device with balancing valve, 5-40 l/m (1-10 USG/m)
Flushing and draining unit integrated Two drain valves (at the Flow meter and at the safety group) enable the filling and flushing of the system
Wilo Star 3 speed pump S30 with 31 feet of head capacity
USD$ 1,870.80
SKU
N-69
2 In Stock
PAW Hydronic Heating Pump Station K31-1"
Plug and Play Hydronic heating and cooling solutions with PAW Modular Zone Pump Stations. With German Engineered PAW modular pump stations you can design heating system quickly while delivering the highest performance and quality standards in the industry. The PAW Zone pump module quickly connects to a centralized distribution manifold allowing you to share the heat source to multiple zones. Now you can easily design a complete home hydronic system that can do radiant floor heating, domestic hot water, radiators and fan coils, as well as pools and hot tubs. All with one single boiler connection.
The K31 with 1” NPT connections is used for high heating zones that do not require mixing. This can be most zones such as domestic hot water, fan coil radiations and pools or hot tubs. For Hyronic radiant floor heat you should use the K32 Model with electronic mixing valve. Features:
1” NPT female connections
Large ball valves handles
Fully insulated enclosure using EPP
Check Valve built into the return piping
Reversible supply and return on right or left side (field changeable)
All brass construction
Metal temperature gauges
Pump isolation for quick system repair
Includes Grundfos ALPHA 25-55 U
Technical Specifications
TECHNICAL DATA Zone Module K31
Dimension
1"- DN 25
Materials
Fittings
Bras
Gaskets
EPDM/NBR
Insulation
EPP
Technical Data
Max. Pressure
116 psi/8 bar
Max. Temprature
230 'F/110 'C
CV value
6.3
Dimensions
Zone module inlet
11/2"male
Zone module outlet
1" NPT F
Center distance
125 mm/421/32"
Length
368 mm/14.5"
Width insulation
250 mm/927/32"
Height insulation
383 mm/15"
Recommended application
High/floating temprature zone control up to 85.5 kBTU/h/25.0 kW at △T = 18 'F/10 K
+
USD$ 1,122.96
SKU
N-404
Out of stock. This item can be backordered. Approx. lead time: 6 weeks.
PAW Hydronic Heating Pump Station K32-1"
Plug and Play Hydronic heating and cooling solutions with PAW Modular Zone Pump Stations. With German Engineered PAW modular pump stations you can design heating system quickly while delivering the highest performance and quality standards in the industry. The PAW Zone pump module quickly connect to a centralized distribution manifold allowing you to share the heat source to multiple zones. Now you can easily design a complete home hydronic system that can do radiant floor heating, domestic hot water, radiators and fan coils, as well as pools and hot tubs. All with one single boiler connection. The K32 with 1” NPT connections is used for low temperature heating zones that require lower output temperatures such as hydronic floor heating. The built in electronic mixing valve is used for Heating Curves that optimize the system’s performance. Using precise temperature control, the electronic mixing valve receives signals to open and close depending on the heating curve, supply temperatures and outdoor temperatures. In this way your hydronic heating zones always stay constant with no fluctuations. The mixing valve diverters’ colder radiant return water with hotter supply water to give your system the exact temperature required. Requires Electronic Mixing Valve Features:
1” NPT female connections
Electronic Mixing Valve can also be adjusted manually
Large ball valves handles
Fully insulated enclosure using EPP
Check Valve built into the return piping
Reversible supply and return on right or left side (field changeable)
All brass construction
Metal temperature gauges
Pump isolation for quick system repair
Includes Grundfos ALPHA 25-55 UU
Technical Specifications TECHNICAL DATA Zone Module K32
Dimension
1"- DN 25
Materials
Fittings
Bras
Gaskets
EPDM/NBR
Insulation
EPP
Technical Data
Max. Pressure
116 psi/8 bar
Max. Temprature
230 'F/110 'C
CV value
4.4
Dimensions
Zone module inlet
11/2" male
Zone module outlet
1" NPT F
Center distance
125 mm/421/32"
Length
368 mm/14.5"
Width insulation
250 mm/927/32"
Height insulation
383 mm/15"
Recommended application
High/floating temprature zone control up to 56.5 kBTU/h/16.5 kW at △T = 18 'F/10 K
+
USD$ 1,262.46
SKU
N-405
2 In Stock
Grundfos UPS26-99FC
The Grundfos UPS26-99FC is a medium duty circulation pump with a Max flow of 33 GPM and a Head of 29 feet. Ideal for all our line of heat pumps. This is also a great pump for larger hydronic heat loops that require more power. 1/6 HP cast iron pump comes with a built in check valve. Built in automatic thermal protection ensure the pump safety. Download Technical Specifications Applications:
Closed loop radiant heating & snow melting systems.
Baseboard/Radiator/Fan coil heating and other hydronic heating applications.
And others.
Features:
Built-in motor protection for longer life and better performance.
Suitable for a wide range of applications, including radiant heating, hydronic heating, fan coil heating, solar and other system types.
Whisper-quiet operation for sound sensitive installations.
Includes (2) Gaskets (O-rings).
UL/CSA listed.
Technical Specifications:
Voltage: 230 VAC
Amperage at Speed 1: 1.3 Amps;
Amperage at Speed 2: 1.5 Amps;
Amperage at Speed 3: 1.8 Amps;
Hertz: 60 Hz;
Phase: 1;
Watts at Speed 1: 150W;
Watts at Speed 2: 179W;
Watts at Speed 3: 197W;
Max Pressure: 145 psi;
Max Temperature: 230F;
Min Temperature: 36F;
Flow Range: 0-33 GPM;
Head Range: 0-29 ft;
Horse Power: 1/6HP;
Body: Cast Iron;
Connections: Flanged, 1/2", 3/4", 1", 1-1/4";
Warranty: 2 years from the date of installation
USD$ 595.41
SKU
N-352
22 In Stock
Grundfos 1” Flange Kit for UPS and ALPHA pumps
Grundfos Flange Kit - 1" FTP +
USD$ 29.85
SKU
N-432
6 In Stock
Grundfos Alpha2 26-99FC Variable Speed Circulator Pump PN-99490916
Grundfos ALPHA2 26-99FC Variable Speed Circulator Pump
with AUTOADAPT PN-99490916 PN-99490916, 1x115V 60Hz, Check Valve Included The Grundfos ALPHA2 26-99 is a medium sized, energy efficient circulator fitted with a permanent magnet motor (ECM) and frequency converter. Featuring eight different operating modes including constant pressure AUTOADAPT and proportional pressure AUTOADAPT, the ALPHA2 26-99 is the perfect fit for any heating application.
AUTOADAPT functionality enables the ALPHA2 26-99 to control operation automatically within a defined performance range. When set in proportional pressure AUTOADAPT or constant pressure AUTOADAPT, the pump will automatically analyze the heating system, find the optimum system curve and duty point and continue to adjust its operation to changes in demand. A magnetite resistant design, robust ceramic shaft and stainless-steel bearing plate ensure that the ALPHA2 26-99 reliably delivers the optimal system flow at the lowest possible energy consumption.
ALPHA2 26-99 circulator pumps are designed for circulating liquids in heating and airconditioning systems. These circulators are equipped with a conduit box for easy installation of the power cable. ALPHA2 26-99 models are internally controlled and are designed for systems with variable flow rates, where the pump is internally controlled via a user interface. Speed control can reduce power consumption considerably. Grundfos ALPHA2 26-99FC Features:
8 intelligent control modes:
Three defined proportional pressure curve settings
Three defined constant pressure curve settings
Constant pressure AUTOADAPT
Proportional pressure AUTOADAPT
Magnetite resistant design protects the pump from harmful iron oxide found in heating systems
High efficiency pump design and controls reduce energy consumption by up to 85%
360 [mNm] starting torque clears pump of system debris and sediment
Designed with trusted ECM technology which has been used by Grundfos for more than 16 years
System and pump protection warning and alarm indicators
LED light indicators for pump settings and alarms
Easy to use push button control settings
Designed using 65+ years of hydronic heating experience
Applications:
Closed loop radiant heating & snow melting systems, solar thermal secondary loops
Baseboard/Radiator/Fan coil heating and other hydronic heating applications.
Air Source Heat pumps (hydronic)
Geothermal de-super heaters
Multiple Zones
Technical Specifications of Grundfos ALPHA2 26-99FC :
Flow Range: 0 - 26 gpm (0 - 5.9 m 3/h)
Head Range: 0 - 42 ft (0 - 12.8 m)
Supply voltage: 1 x 115 V, + 10 %/- 10 %, 60 Hz
Power usage (approximate): 3 - 120 W
Amps: Max. 1.7 A
Horsepower: 0.16 hp
Min. Fluid Temperature: 14 °F (-10 °C)
Max. Fluid Temperature (continuously): 203 °F (95 °C)
Max. Outlet Pressure: 150 psi (10 bar)
Flange-to-flange length: 6.5 in (165 mm)
Pump housing: Cast iron
Approvals: cULus Listed
Warranty: 3 years manufacturer's warranty. Pump Curve + Dimensions +
USD$ 742.45
SKU
N-372
41 In Stock
Solar Feed Pump Station - ST-Pump-Feeder-MF 200 - S
Solar Feed Pump Station - ST-Pump-Feeder-MF 200 - S MODEL MF200-S ‘SOLAR PAL’ MINI SYSTEM FEEDER
The ‘SOLAR PAL’ is designed for application with Solar systems collectors typicaly mounted high on the structure that may require higher static fill pressures than conventional residential and light commercial projects. The system feeder can provide fill pressure as high as 35 psig. It is compatible with water and most commonly used anti-freeze solutions.
NOTE – the system pressure relief valve must be rated to handle the higher pressure. Do not use the MF200-S in any application with a 30psig relief valve. Features:
22.7 liter (6.0 US gallon) tank for storage and mixing
Power supply plugs into any standard 115 VAC outlet
Diaphragm pump can run dry without damage
No direct connection to potable water supply eliminates need for backflow prevention
Make-up fluid stored in the feeder tank can be pre-treated
Diverter valve allows easy purging of air on initial start-up, and manual agitation of solution
Prevents major floods - in the event of system rupture, only the contents of the tank will be pumped into the system
Provides leak detection - dropping fluid level provides immediate notice that the system has developed a leak
Fluid drained for service can easily be put back into the system
Fluid level switch shuts the pump off if the storage tank level gets too low
Auxiliary dry contact included for remote low pressure alarm (alarm optional or by others)
ELECTRICAL:
Fused Power supply adapter 115/60/1 to 24 VDC Rated 50 watts AC LED Power Light
PUMP PERFORMANCE:
0.04 l/s (0.7 gpm) @ free flow Self-priming up to 1.2 m (4 feet)
+
USD$ 863.78
SKU
N-293
Out of stock. This item can be backordered. Approx. lead time: 6 weeks.
PAW ACTUATOR SR10 - 24V
PAW Actuator SR10 - 24V Required by PAW K32 Pump Station For Weather compensated controls such as the RESol MX. Change over from manual mix to electronic operation. Automatically maintains the proper water temperature for both heating and cooling heating curves. 24 VAC control. TECHNICAL DATA
Electrical Connection – 24 VAC/DC
Input Power - 3.5 W
Actuation time 90 – 140 seconds
USD$ 242.20
SKU
N-406
